Operating conditions
Temperature:-40℃~125℃
Pressure:≤1.2MPa
Speeds: ≤13m/sec
Applications: Used in different pumps, mixers and other rotating equipments which apply to oil, water and other weak corrosive solutions.
Materials
Rotary ring(Carbon/SiC/TC)
Stationary ring(Ceramic/SiC/TC)
Secondary seal(NBR/EPDMNITON)
Spring & Other parts (SUS304/SUS316)
型號MODEL | D1 | D3 | D7 | L | L3 | L4 |
JD109-12 | 12 | 24 | 26 | 21/21.5 | 16 | 5/5.5 |
JD109-12T | 12 | 24 | 26 | 21 | 13 | 8 |
JD109T-12 | 12 | 23.5 | 26 | 20.5 | 14 | 6.5 |
JD109-14 | 14 | 28.5 | 28/30 | 23/25 | 17.5 | 5.5/7.5 |
JD109-14T | 14 | 28.5 | 30 | 21 | 14 | 7 |
JD109T-14 | 14 | 28.5 | 28/30 | 20.5/22.5 | 15 | 5.5/7.5 |
JD109-15 | 15 | 28.5 | 28/30 | 23/25 | 17.5 | 5.5/7.5 |
JD109-16 | 16 | 28.5 | 28/30 | 23/25 | 17.5 | 5.5/7.5 |
JD109-17 | 17 | 31 | 33/34/35/36 | 24.5/27 | 19.5 | 5/7.5 |
JD109-18 | 18 | 31 | 33/34/35/36 | 24.5/27 | 19.5 | 5/7.5 |
JD109-19 | 19 | 36.5 | 35/36 | 26.5/29 | 21.5 | 5/7.5 |
JD109-20 | 20 | 36.5 | 35/36 | 26.5/29 | 21.5 | 5/7.5 |
JD109-22 | 22 | 36.5 | 37 | 29 | 21.5 | 7.5 |
JD109-24 | 24 | 41 | 39 | 30 | 22.5 | 7.5 |
JD109-25 | 25 | 41 | 40/(41) | 30.5/(29.5) | 22.5 | 8/(7) |
JD109-27 | 27 | 43 | 42 | 35 | 26.5 | 8.5 |
JD109-28 | 28 | 47.5 | 43 | 34 | 26.5 | 7.5 |
JD109-30 | 30 | 47.5 | 45 | 34 | 26.5 | 7.5 |
JD109-32 | 32 | 52 | 48 | 35 | 27.5 | 7.5 |
JD109-33 | 33 | 52 | 48 | 35 | 27.5 | 7.5 |
JD109-35 | 35 | 55 | 50 | 36 | 28.5 | 7.5 |
JD109-38 | 38 | 58.5 | 56 | 39 | 30 | 9 |
JD109-40 | 40 | 60 | 58 | 39 | 30 | 9 |
JD109-42 | 42 | 65 | 61 | 39 | 30 | 9 |
JD109-43 | 43 | 65 | 61 | 39 | 30 | 9 |
JD109-45 | 45 | 68 | 63 | 39 | 30 | 9 |
JD109-48 | 48 | 70.5 | 66 | 39.5 | 30.5 | 9 |
JD109-50 | 50 | 72 | 70 | 40 | 30.5 | 9.5 |
JD109-53 | 53 | 78.5 | 73 | 44 | 33 | 11 |
JD109-55 | 55 | 81 | 75 | 46 | 35 | 11 |
JD109-58 | 58 | 85.5 | 78 | 48 | 37 | 11 |
JD109-60 | 60 | 88.5 | 80 | 49 | 38 | 11 |
JD109-65 | 65 | 91 | 85 | 51 | 40 | 11 |
JD109-68 | 68 | 97 | 90 | 51.3 | 40 | 11.3 |
JD109-70 | 70 | 97 | 92 | 51.3 | 40 | 11.3 |
JD109-75 | 75 | 105 | 97 | 51.3 | 40 | 11.3 |
JD109-80 | 80 | 109 | 105 | 52 | 40 | 12 |
JD109-85 | 85 | 120 | 110 | 55 | 41 | 14 |
JD109-90 | 90 | 127 | 115 | 59 | 45 | 14 |
JD109-95 | 95 | 132 | 120 | 60 | 46 | 14 |
JD109-100 | 100 | 135 | 125 | 61 | 47 | 14 |
