Operating conditions
Temperature:-40~150℃
Pressure:≤0.5MPa
Speeds:≤10m/sec
Applications: Used in automobile engine cooling water pump
Materials
Rotary ring(Ceramic/SiC)
Stationary ring(Carbon/SiC)
Secondary seal(NBR/HNBR/EPDMNITON)
Spring & Other parts(SUS304)
型號MODEL | D1 | D2 | D3 | D5 | D7 | L1 | L4 |
JDFB-12S | 12 | 28.55 | 32.0 | 18.5 | 25/26 | 17.5 | 8.0 |
JDFB-12M | 12 | 30.00 | 35.0 | 18.5 | 25/26 | 17.5 | 8.0 |
JDFB-12L | 12 | 33.40 | 38.0 | 18.5 | 25/26 | 17.5 | 6.7 |
JDFB-13 | 13 | 30.00 | 35.0 | 18.5 | 25/26 | 18.0 | 8.0 |
JDFB-15 | 15 | 36.45 | 41.5 | 22.5 | 30.5 | 20.5 | 8.5 |
JDFB-16 | 16 | 36.45 | 41.5 | 22.5 | 30.5 | 20.5 | 8.5 |
JDFB-16B | 16 | 36.45 | 41.5 | 22.5 | 28.0 | 20.0 | 8.5 |
JDFB-16T | 16 | 36.45 | 41.45 | 19.3 | 31.5 | 20.5 | 9.0 |
JDFB-16T | 16 | 38.10 | 43.5 | 22.5 | 30.5 | 20.5 | 8.8 |
JDFB-16LD | 16 | 38.10 | 43.5 | 22.5 | 28.5 | 20.5 | 8.8 |
JDFB-20 | 20 | 38/40 | 43.8 | 26.5 | 37.0 | 22.0 | 9.5 |
JDFB-20T | 20 | 40.00 | 43.8 | 28.0 | 37.0 | 22.0 | 9.5 |
